[GH-ISSUE #97] rsyslog : imudp: Could not create udp listener #49
Loading…
Add table
Add a link
Reference in a new issue
No description provided.
Delete branch "%!s()"
Deleting a branch is permanent. Although the deleted branch may continue to exist for a short time before it actually gets removed, it CANNOT be undone in most cases. Continue?
Originally created by @GordonSasha on GitHub (Aug 26, 2021).
Original GitHub issue: https://github.com/konstruktoid/hardening/issues/97
Hi Thomas,
you are making a great job - thank you very much.
I have installed the version v1.0.0 on our device and now testing the
functionality of all the features under hardening. I am currently
investigating the syslog problem and cannot figure out
what is happening. I would be very grateful if you can help me with this.
Problem:
rsyslog imudp plugin can't create udp listener
/-----------------------------------------------------------------/
$ sudo systemctl status rsyslog.service
● rsyslog.service - System Logging Service
Loaded: loaded (/lib/systemd/system/rsyslog.service; enabled; vendor preset: enabled)
Active: active (running) since Thu 2021-08-26 08:06:26 UTC; 8s ago
TriggeredBy: ● syslog.socket
Docs: man:rsyslogd(8)
https://www.rsyslog.com/doc/
Main PID: 3980 (rsyslogd)
Tasks: 4 (limit: 9281)
Memory: 1.0M
CGroup: /system.slice/rsyslog.service
└─3980 /usr/sbin/rsyslogd -n -iNONE
Aug 26 08:06:26 tfence-sideB systemd[1]: Started System Logging Service.
Aug 26 08:06:26 tfence-sideB rsyslogd[3980]: create UDP socket bound to device failed: Operation not permitted [v8.2001.0]
Aug 26 08:06:26 tfence-sideB rsyslogd[3980]: create UDP socket bound to device failed: Operation not permitted [v8.2001.0]
Aug 26 08:06:26 tfence-sideB rsyslogd[3980]: No UDP socket could successfully be initialized, some functionality may be disabled. [v8.2001>
Aug 26 08:06:26 tfence-sideB rsyslogd[3980]: imudp: Could not create udp listener, ignoring port 514 bind-address (null). [v8.2001.0]
Aug 26 08:06:26 tfence-sideB rsyslogd[3980]: imudp: no listeners could be started, input not activated. [v8.2001.0]
Aug 26 08:06:26 tfence-sideB rsyslogd[3980]: activation of module imudp failed [v8.2001.0 try https://www.rsyslog.com/e/-3 ]
Aug 26 08:06:26 tfence-sideB rsyslogd[3980]: rsyslogd's groupid changed to 110
Aug 26 08:06:26 tfence-sideB rsyslogd[3980]: rsyslogd's userid changed to 104
Aug 26 08:06:26 tfence-sideB rsyslogd[3980]: [origin software="rsyslogd" swVersion="8.2001.0" x-pid="3980" x-info="https://www.rsyslog.com">
/-----------------------------------------------------------------/
Testing configuration:
syslog message -->|--> eth0 -----> use imudp ---> eth1 ----|--> syslogserver
| 10.0.0.2 172.16.1.2 | 172.16.1.50
|-------------------------------------------|
Client1 $ logger --server 10.0.0.2 --udp --port 514 "$i) udp message from Client1";
Tested Device (tgate) config:
/etc/rsyslog.d/10-relay.conf :
/~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~/
$template msg_format, "%rawmsg%\n"
module(load="builtin:omfwd" Template="msg_format")
module(load="imudp")
input(type="imudp" port="514" device="eth0" ruleset="rs1")
Ruleset(name="rs1") {
action(type="omfwd" target="172.16.1.50" port="514" protocol="udp")
& stop
}
/~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~/
with tcpdump I see the packages are arriving to the "eht0":
$ sudo tcpdump -i eth0 -nn -v udp and port 514
but "eth1" does not received them:
$ sudo tcpdump -i eth1 -nn -v udp and port 514
Versions:
hardening: v1.0.0 downloaded 14 apr 2021
Tested Device (tgate) OS:
tgate :$ cat /etc/lsb-release
DISTRIB_ID=Ubuntu
DISTRIB_RELEASE=20.04
DISTRIB_CODENAME=focal
DISTRIB_DESCRIPTION="Ubuntu 20.04.2 LTS"
rsyslog verion:
rsyslogd: version 8.2001.0
If you have any ideas, suggestions, or you know another way to solve the problem, I would love to hear them.
Thank you in advance
@GordonSasha commented on GitHub (Aug 26, 2021):
If you can send a reply to mail: sasha.gordon@gmail.com I am very grateful
@konstruktoid commented on GitHub (Aug 26, 2021):
Hi @GordonSasha, it seems to be a permission issue (
create UDP socket bound to device failed: Operation not permitted, are you restarting the service usingsudo?) but without additional logs I'll have a hard time helping out.Since you also working with routing etc
syslog message -->|--> eth0 -----> use imudp ---> eth1 ----|--> syslogserver, this issue is out-of-scope for this project.@GordonSasha commented on GitHub (Aug 26, 2021):
In general, this can be referred to as routing log messages. But in fact rsyslog does not receive messages because it cannot load the plugin. I have attached the log file of a running rsyslog in the debug module. You can see the problem (line 2174 ...). The same configuration works correctly on the device without hardening, so I think one (or more) of the hardening steps affects rsyslog. Retranslating syslog messages are not uncommon. I sure, if you will want, you can simple repeir the problem.
If you need an additional information - let me know.
Big thanks
#~~~~~~~~~~~~~~~~ from line 2174
6849.677339702:main thread : ratelimit.c: ratelimit:imuxsock:new ratelimiter:bReduceRepeatMsgs 1
6849.677461450:main thread : errmsg.c: Called LogMsg, msg: cannot create '/run/systemd/journal/syslog'
6849.677473552:main thread : operatingstate.c: osf: MSG cannot create '/run/systemd/journal/syslog': rsyslogd: cannot create '/run/systemd/journal/syslog': Address already in use [v8.2001.0 try https://www.rsyslog.com/e/2176 ]
imuxsock: Opened UNIX socket '/var/spool/postfix/dev/log' (fd 4).
6849.678023396:main thread : rsconf.c: pre priv drop activating config 0x56131e9b1fd0 for module imklog
6849.678070038:main thread : rsconf.c: pre priv drop activating config 0x56131e9b1fd0 for module imudp
6849.678087079:main thread : imudp.c: Trying to open syslog UDP ports at *:514.
6849.678430655:main thread : errmsg.c: Called LogMsg, msg: create UDP socket bound to device failed
6849.678449122:main thread : operatingstate.c: osf: MSG create UDP socket bound to device failed: rsyslogd: create UDP socket bound to device failed: Operation not permitted [v8.2001.0]
Called LogMsg, msg: create UDP socket bound to device failed
#~~~~~~~~~~~~~~~
rsyslog_imudp.log
@konstruktoid commented on GitHub (Aug 26, 2021):
Address already in use, is there another instance ofrsyslogrunning on port 514 already?@GordonSasha commented on GitHub (Aug 26, 2021):
No, anyone don't listen on the 514.
@GordonSasha commented on GitHub (Aug 26, 2021):
sudo netstat -tulpn | grep LISTEN
[sudo] password for tfence:
tcp 0 0 127.0.0.53:53 0.0.0.0:* LISTEN 643/systemd-resolve
tcp 0 0 0.0.0.0:22 0.0.0.0:* LISTEN 719/sshd: /usr/sbin
tcp 0 0 127.0.0.1:25 0.0.0.0:* LISTEN 1357/master
tcp 0 0 127.0.0.1:7883 0.0.0.0:* LISTEN 678/mosquitto
tcp6 0 0 :::22 :::* LISTEN 719/sshd: /usr/sbin
tcp6 0 0 ::1:25 :::* LISTEN 1357/master
@GordonSasha commented on GitHub (Aug 26, 2021):
netstat -l
Active Internet connections (only servers)
Proto Recv-Q Send-Q Local Address Foreign Address State
tcp 0 0 127.0.0.53:domain 0.0.0.0:* LISTEN
tcp 0 0 0.0.0.0:ssh 0.0.0.0:* LISTEN
tcp 0 0 localhost:smtp 0.0.0.0:* LISTEN
tcp 0 0 localhost:7883 0.0.0.0:* LISTEN
tcp6 0 0 [::]:ssh [::]:* LISTEN
tcp6 0 0 ip6-localhost:smtp [::]:* LISTEN
udp 0 0 127.0.0.53:domain 0.0.0.0:*
udp 0 0 172.16.1.52:ntp 0.0.0.0:*
udp 0 0 10.0.0.2:ntp 0.0.0.0:*
udp 0 0 localhost:ntp 0.0.0.0:*
udp 0 0 0.0.0.0:ntp 0.0.0.0:*
udp 0 0 10.0.0.255:51101 0.0.0.0:*
udp 0 0 10.0.0.255:51102 0.0.0.0:*
udp6 0 0 fe80::260:e9ff:fe2b:ntp [::]:*
udp6 0 0 fe80::260:e9ff:fe2b:ntp [::]:*
udp6 0 0 ip6-localhost:ntp [::]:*
udp6 0 0 [::]:ntp [::]:*
raw6 0 0 [::]:ipv6-icmp [::]:* 7
raw6 0 0 [::]:ipv6-icmp [::]:* 7
Active UNIX domain sockets (only servers)
Proto RefCnt Flags Type State I-Node Path
unix 2 [ ACC ] SEQPACKET LISTENING 18231 /run/udev/control
unix 2 [ ACC ] STREAM LISTENING 56071 /run/user/1000/systemd/private
unix 2 [ ACC ] STREAM LISTENING 56076 /run/user/1000/bus
unix 2 [ ACC ] STREAM LISTENING 56077 /run/user/1000/gnupg/S.dirmngr
unix 2 [ ACC ] STREAM LISTENING 56078 /run/user/1000/gnupg/S.gpg-agent.browser
unix 2 [ ACC ] STREAM LISTENING 56079 /run/user/1000/gnupg/S.gpg-agent.extra
unix 2 [ ACC ] STREAM LISTENING 18213 @/org/kernel/linux/storage/multipathd
unix 2 [ ACC ] STREAM LISTENING 56080 /run/user/1000/gnupg/S.gpg-agent.ssh
unix 2 [ ACC ] STREAM LISTENING 56081 /run/user/1000/gnupg/S.gpg-agent
unix 2 [ ACC ] STREAM LISTENING 56082 /run/user/1000/pk-debconf-socket
unix 2 [ ACC ] STREAM LISTENING 28078 @usbguard@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@
unix 2 [ ACC ] STREAM LISTENING 30817 public/pickup
unix 2 [ ACC ] STREAM LISTENING 30821 public/cleanup
unix 2 [ ACC ] STREAM LISTENING 30824 public/qmgr
unix 2 [ ACC ] STREAM LISTENING 30828 private/tlsmgr
unix 2 [ ACC ] STREAM LISTENING 30831 private/rewrite
unix 2 [ ACC ] STREAM LISTENING 30834 private/bounce
unix 2 [ ACC ] STREAM LISTENING 30837 private/defer
unix 2 [ ACC ] STREAM LISTENING 30840 private/trace
unix 2 [ ACC ] STREAM LISTENING 30843 private/verify
unix 2 [ ACC ] STREAM LISTENING 30846 public/flush
unix 2 [ ACC ] STREAM LISTENING 30849 private/proxymap
unix 2 [ ACC ] STREAM LISTENING 30852 private/proxywrite
unix 2 [ ACC ] STREAM LISTENING 30855 private/smtp
unix 2 [ ACC ] STREAM LISTENING 30858 private/relay
unix 2 [ ACC ] STREAM LISTENING 30861 public/showq
unix 2 [ ACC ] STREAM LISTENING 30864 private/error
unix 2 [ ACC ] STREAM LISTENING 30867 private/retry
unix 2 [ ACC ] STREAM LISTENING 30870 private/discard
unix 2 [ ACC ] STREAM LISTENING 30873 private/local
unix 2 [ ACC ] STREAM LISTENING 30876 private/virtual
unix 2 [ ACC ] STREAM LISTENING 30879 private/lmtp
unix 2 [ ACC ] STREAM LISTENING 30882 private/anvil
unix 2 [ ACC ] STREAM LISTENING 30885 private/scache
unix 2 [ ACC ] STREAM LISTENING 30891 private/maildrop
unix 2 [ ACC ] STREAM LISTENING 30894 private/uucp
unix 2 [ ACC ] STREAM LISTENING 30897 private/ifmail
unix 2 [ ACC ] STREAM LISTENING 30900 private/bsmtp
unix 2 [ ACC ] STREAM LISTENING 30903 private/scalemail-backend
unix 2 [ ACC ] STREAM LISTENING 30906 private/mailman
unix 2 [ ACC ] STREAM LISTENING 18200 /run/systemd/private
unix 2 [ ACC ] STREAM LISTENING 18202 /run/systemd/userdb/io.systemd.DynamicUser
unix 2 [ ACC ] STREAM LISTENING 18211 /run/lvm/lvmpolld.socket
unix 2 [ ACC ] SEQPACKET LISTENING 18216 /run/systemd/coredump
unix 2 [ ACC ] STREAM LISTENING 18226 /run/systemd/journal/stdout
unix 2 [ ACC ] STREAM LISTENING 15634 /run/systemd/journal/io.systemd.journal
unix 2 [ ACC ] STREAM LISTENING 23484 /run/dbus/system_bus_socket
unix 2 [ ACC ] STREAM LISTENING 23486 /run/uuidd/request
@konstruktoid commented on GitHub (Aug 26, 2021):
Can you include you rsyslog configuration so I can test with an exact copy?
@GordonSasha commented on GitHub (Sep 5, 2021):
Sorry for the delay and silence. I was ill.
At your request,
rsyslog_config.zip
sending you syslog configuration files
Sorry again and thanks in advance
@konstruktoid commented on GitHub (Sep 5, 2021):
No need to apologise, glad you've gotten better.
I'll have a look at the config as soon as possible.
@GordonSasha commented on GitHub (Sep 5, 2021):
Thanks a lot for your help. I opened additional bug about apt error. But
look like I know what's a problem. I can check it only at the Thursday. We
on holiday s vacation
Thanks
On Sun, Sep 5, 2021, 19:02 Thomas Sjögren @.***> wrote:
@konstruktoid commented on GitHub (Sep 7, 2021):
Check the
devicesetting on ther servers. That one of the reason that error occured.I also tested and got it working with a rewritten config file.
@GordonSasha commented on GitHub (Sep 9, 2021):
Sorry for the delay and silence. I was ill.
At your request,
rsyslog_config.zip
sending you syslog configuration files
Sorry again and thanks in advance
@GordonSasha commented on GitHub (Sep 9, 2021):
Hi, I found when problem is appearing. One of the apparmor profiles prevent to create UDP socket of the rsyslog. It happend in f_aa_enforce() function.
@GordonSasha commented on GitHub (Sep 14, 2021):
the solution is :
echo "capability net_raw," > /etc/apparmor.d/local/usr.sbin.rsyslogd
@konstruktoid commented on GitHub (Sep 14, 2021):
great catch, i can add that check if you don't want to submit a PR.
pushing upstream?
@GordonSasha commented on GitHub (Sep 14, 2021):
I think you can add it better than me.
@github-actions[bot] commented on GitHub (Oct 15, 2021):
This issue is stale because it has been open 30 days with no activity, without any activity it will be closed in 5 days.
